ECOWIZ Mobile Pyrolysis System for Smarter, Cleaner Waste Management
Eco-friendly waste processing made simple.
NO Toxic Byproducts
NO Black Fumes
NO Bad Smell
KEY BENEFITS
A Smarter Way to Process Waste, Wherever It Happens
ECOWIZ M4-VHPF is a mobile, four-phase vortex pyrolysis furnace. It operates using electromagnetic field induced plasma pyrolysis technology.
Eco-friendly
Complete thermal decomposition of municipal solid waste using our proprietary M4-VHPF technology.
Low Cost
Operates on household electricity only, no auxiliary fuels like gas, oil, or urea water needed.
No Pollutants
Emits almost no air pollutants, smoke, or odors.
No Secondary Damage
Prevents environmental harm to soil and groundwater.
Mobile
Portable and ready to use within a few hours.
Zero Waste
Complete combustion leaves minimal ash, suitable for building materials.
TECHNICAL SPECIFICATIONS
System Specifications & Key Details
Explore the key technical details that define ECOWIZ’s performance. From waste processing capacity to power usage and environmental output, this provides a clear view of how ECOWIZ works and what makes it a reliable, eco friendly solution for on site waste management.
Mobile Four-phase Vortex High-Temperature Pyrolysis Furnace Kit
Model Name
Product Name
Type
Installation Type
Capacity
Dimensions (W x L x H)
Total Weight
Power Requirements
Key Features
EVP (Non Dust Collector Kit Type)
ECOWIZ
Mobile Four-phase Vortex High-Temperature Pyrolysis Furnace Kit
Mobile
30 kg/hr / 50 kg/hr / 100 kg/hr
1600 x 3000 x 2500 / 1600 x 3000 x 2500 / 1600 x 3500 x 2500
2.5 tons / 3 tons / 4 tons
220V-3P 60Hz (50Hz)
ULB - Ultra Low Emission, WTE, IWMF, CO2 Capture, IoT - A
Ecowiz Optional Attachments:
Option:
MODEL EVP DCHE
Dust Collector (Multi-Cyclone) Heat Exchanger (Hot water supply type)
Option:
MODEL EVP with MCyclone
Dust Collector (Multi-Cyclone)
Cross-Flow Vortex Pyrolysis Furnace
Model Name
Product Name
Type
Installation Type
Cooling System
Capacity
Power Requirements
Fuel
Key Features
EVHP-A / EVHP-W
ECOWIZ
Cross-Flow Vortex Pyrolysis Furnace
Stationary / Mobile
Air-cooled / Water-cooled
Mobile: 100 kg/hr / 150 kg/hr
Stationary: 200 kg/hr
Stationary (Air Pollution Control Facility):
100 kg/hr / 150 kg/hr / 200 kg/hr / 300 kg/hr / 500 kg/hr / 1000 kg/hr
(Custom High-Capacity Models Available)
440V / 60Hz (50Hz)
LPG, Diesel, Kerosene, Pyrolysis Oil
ULB - Ultra Low Emission, WTE, IWMF, CO2 Capture, IoT - AI
Patents and Certifications
Verified Innovation with Certified Quality
Our technologies are protected by registered patents and recognized through local quality certifications, reflecting our commitment to reliable performance and continuous improvement.
